| Features |
MIG130
|
MIG160
|
MIG145 Pro
|
MIG200
|
MIG250
|
MIG205 Pro
|
MIG205 MP
|
MIG200 Fit
|
|---|---|---|---|---|---|---|---|---|
| Model |
$109.99
$169.99
|
$189.99
$229.99
|
$189.99
$229.99
|
$359.99
$499.99
|
$499.99
$599.99
|
$649.99
$799.99
|
$799.00
$1,205.00
|
$309.99
$349.99
|
| INPUT Voltage(Volts) | 110 | 110/220 | 120 | 110/220 | 110/220 | 120/240 | 120/240 | 110/220 |
| Multi Process | MIG/Gasless MIG/Stick/Lift TIG | MIG/Gasless MIG/Stick/Lift TIG | MIG/Gasless MIG/Stick/Lift TIG | MIG/Gasless MIG/Stick/Lift TIG/Spot | MIG/Gasless MIG/Stick/Lift TIG/Spot | MIG/Gasless MIG/Stick/Lift TIG/Spot | MIG/Gasless MIG/MIG Pulse/Stick/HF-TIG/Lift TIG/CUT/Clean/Spot | MIG/Gasless MIG/Stick/Lift TIG/Spot |
| Output Welding current range(MMA) | 20～130A | 110V: 20～120A 220V: 20～160A |
20-145A | 110V: 20～135A 220V: 20～180A |
110V: 20～175A 220V: 20～250A |
120V: 20～140A 240V: 20～205A |
120V: 20～140A 240V: 20～205A |
110V: 20～140A 220V: 20～200A |
| Output Welding current range(TIG) | 20-130A | 110V: 20～120A 220V: 20～160A |
20-145A | 110V: 20～135A 220V: 20～200A |
110V: 20～175A 220V: 20～250A |
120V: 20～140A 240V: 20～205A |
120V: 20～140A 240V: 20～205A |
110V: 20～140A 220V: 20～200A |
| Output Welding current range(MIG) | 20-130A | 110V: 40～120A 220V: 40～160A |
40-145A | 110V: 30～160A 220V: 30～200A |
110V: 20～175A 220V: 20～250A |
120V: 30～140A 240V: 30～205A |
120V: 20～140A 240V: 20～205A |
110V: 20～140A 220V: 20～200A |
| Output Current Range(CUT) | No | No | No | No | No | No | 120V: 20-40A 240V: 20-50A |
No |
| Wire feed speed range | 30-270ipm | 30-315ipm | 30-270ipm | 110V: 79～473 ipm 220V: 79～590 ipm |
59-630ipm | 120V: 60-480 ipm 240V: 60-640 ipm |
120V: 60-480 ipm 240V: 60-640 ipm |
80-550ipm |
| Support Spool Gun | No | No | No | Yes | Yes | Yes | Yes | Yes |
| Support Foot Pedal | No | No | No | No | No | No | Yes | No |
| Parameter Storage | No | No | No | Yes | Yes | Yes | Yes | Yes |
| App Control | No | No | Yes | No | No | Yes | Yes | No |
| Recommend Welding Thickness | 20Ga(0.9mm)-10Ga(4mm) | 20Ga(0.9mm)-3/16"(5mm) | 20Ga(0.9mm)-10Ga(4mm) | 20Ga(0.9mm)-5/16"(8mm) | 20Ga(0.9mm)-3/8"(10mm) | 20Ga(0.9mm)-3/8"(10mm) | 20Ga(0.9mm)-5/16"(8mm) | 20Ga(0.9mm)-5/16"(8mm) |
| Weldable Metals | Steel/Stainless Steel/Cast Iron |
Steel/Stainless Steel/Cast Iron |
Steel/Stainless Steel/Cast Iron |
Steel/Stainless Steel/Cast/Iron Copper/Aluminum |
Steel/Stainless Steel/Cast/Iron Copper/Aluminum |
Steel/Stainless Steel/Cast/Iron Copper/Aluminum |
Steel/Stainless Steel/Cast/Iron Copper/Aluminum |
Steel/Stainless Steel/Cast/Iron Copper/Aluminum |
| Weight (Lb) | 11.79 | 11.8 | 9.5 | 28.2 | 20.5 | 20.5 | 21.6 | 21.6 |
| Size (Inch) | 14.9 * 5.3 * 9.7 | 15 * 5.3 * 9.7 | 12.8 * 5.7 * 9.7 | 20.9 * 8.5 * 16.1 | 20.3 * 8.1 * 15.2 | 17.3 * 7.9 * 12.7 | 17.3 * 12.7 * 7.9 | 18.5 * 14 * 7.9 |
| Welding Parts |
MIG Gun Parts: MB15 TIG Torch Parts: WP-17/18/26 |
MIG Gun Parts: MB15 TIG Torch Parts: WP-17/18/26 |
MIG Gun Parts: MB15 TIG Torch Parts: WP-17/18/26 |
MIG Gun Parts: MB15 TIG Torch Parts: WP-17/18/26 |
MIG Gun Parts: Lincoln 100L TIG Torch Parts: WP-17/18/26 |
MIG Gun Parts: Lincoln 100L TIG Torch Parts: WP-17/18/26 |
MIG Gun Parts: Lincoln 100L CUT Gun Parts: PT31 TIG Torch Parts: WP-17/18/26 |
MIG Gun Parts: MB15 TIG Torch Parts: WP-17/18/26 |
| Manual | https://cdn.shopify.com/s/files/1/0613/8458/9369/files/ARCCAPTAIN_MIG130.pdf?v=1668413503 | https://cdn.shopify.com/s/files/1/0613/8458/9369/files/MIG160_User_Manual.pdf?v=1733822688 | https://cdn.shopify.com/s/files/1/0613/8458/9369/files/MIG_145_Pro_manual.pdf?v=1727599961 | https://cdn.shopify.com/s/files/1/0613/8458/9369/files/MIG200_USER_MANUAL.pdf?v=1742957791 | https://cdn.shopify.com/s/files/1/0613/8458/9369/files/MIG250_User_Manual.pdf?v=1733822693 | https://cdn.shopify.com/s/files/1/0613/8458/9369/files/MIG205_Pro_manual.pdf?v=1727599886 | https://cdn.shopify.com/s/files/1/0613/8458/9369/files/MIG205MP_User_Manual.pdf?v=1736846270 | https://cdn.shopify.com/s/files/1/0613/8458/9369/files/MIG200Fit_User_Manual.pdf?v=1736846681 |
| Buy Now | Buy Now | Buy Now | Buy Now | Buy Now | Buy Now | Buy Now | Buy Now |
